OCB-GAT23C 4G Wireless Vehicle Accessories Black GPS Magnetic Tracker
Availability (May Vary): In stock
Price:
Sign In for Price
 |
Free Installation |  |
Multi-Platform Monitoring | |||||
| Easily move or remove without causing permanent markings or damage. No need for power supply or wiring connection. | Multi-platform monitoring enables users to track and control the car locator conveniently through different operating systems and platforms. | |||||||
 |
GEO Fence IN/OUT Alarm |  |
Super Long Standby Time | |||||
| GEO fence alerts in car locators trigger when the vehicle enters or exits predefined boundaries. | Allow for extended usage time without the need for frequent charging or battery replacement. | |||||||
 |
Multiple Location Ways |  |
Lighting Alarm | |||||
| Multiple positioning methods, providing versatile tracking capabilities for accurate and reliable vehicle location monitoring. | Enhances security with visual alerts, deterring theft or unauthorized access. |
| Module | |
| Technology | LTE FDD/LTE TDD/4G(GSM/GPRS) |
| GNSS | |
| Positioning System | GPS+Beidou |
| Frequency | GPS L1,1575.42MHz BDS B1,1561.098MHz |
| Positioning Accuracy | ＜10m |
| Tracking Sensitivity | -165dBm |
| Acquisition Sensitivity | -148dBm |
| Positioning Time | Avg. Hot Start <2s Avg. Warm Start <28s Avg. Cold Start <38s |
| Cellular | |
| Communication Network | GSM GPS |
| 4G LTE Cat 1 Bands | LTE-FDD：B1/B3/B5/B8 LTE-TDD:B34/B38/B39/B40/B41 GSM :B3/B8 LTE-FDD:B1/B3/B5/B7/B8/B20 GSM:B1/B3/B5/B8 LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B28/B66 |
| Data Support | SMS (text/data) |
| Power | |
| Internal Battery | 100mAh/3.7V Li-Polymer battery |
| Input Voltage | 9-90V DC with overvoltage and reverse polarity protection |
| Interface | |
| LED Indication | GPS (Blue), GSM (Yellow)，Power (Red) |
| SIM | Micro-SIM |
| Physical specification | |
| Dimensions (L x W x H) | 136.5x32.6x13.9mm |
| Weight | 35g |
| Operating environment | |
| Operating Temperature | –30℃ to +50℃ |
| Operating Humidity | 35% to 80% |
| Waterproof Level | IP65 |
| Feature | |
| Sensors | Temperature Sensor |
| Scenarios | ● GPS+Beidou position ways ● Real-Time Tracking,Oil-Cut function, n Car Acc On/Off Status ● Power Down Alarm,Low Power Alarm, n Over Speed Alarm,Vibration alarm,Geo-fence Alarm ● Blind Area Uploading Data,Inflexion Upload ● Upload data automatically in emergency situation |
